Abgratpresse TMP Voronezh K2535 - 315 ton
Technische Daten (EN) -
Abgratpresse TMP Voronezh K2535 - 315 ton (ID: 75605)
| Type | Trimming press |
| Manufacturer | TMP Voronezh |
| Model | K2535 |
| Made in | Russia |
| Nominal effort | 315 ton |
| Slider stroke | 200 mm |
| Number of continuous strokes | 32/1 min |
| Number of single strokes | 24/1 min |
| Distance between bolster plate and slide | 560 mm |
| Distance adjustment between slide and table | 140 mm |
| Table dimensions | 1000 x 1000 mm |
| Slide dimensions | 800 x 800 mm |
| Press overall dimensions | 3070 x 2940 x 5310 mm |
| Press weight | 26200 kg |
