Hydraulischer Schmiedehammer Eumuco HOG-100 A - 10 ton
Technische Daten (EN) -
Hydraulischer Schmiedehammer Eumuco HOG-100 A - 10 ton (ID: 76225)
| Type | Hydraulic forging hammer |
| Manufacturer | Eumuco |
| Model | HOG-100 A |
| Year of manufacture | 1980 |
| Capacity | 10 ton |
| Work resulting a blow | 10000 kg |
| Stroke | 1270 mm |
| Stroke per minutes | 68~90/min |
| Table size | 480 x 480 mm |
| Height of fall | 590 mm |
| Weight of ram hammer | 7,800 kg |
| Shut height | 330~660 mm |
| Clearance distance between guidance | 940 mm |
| Depth of ram hammer | 1000 mm |
| Power | 2 x 75 kw |
| Weight of anvil bed | 101 ton |
| Total height | 8 m |
| Height From the Floor | 6.7 m |
| Total weight | 143 ton |
