Gesemkschmiedepresse TMP Voronezh K8540 - 1000 ton
Technische Daten (EN) -
Gesemkschmiedepresse TMP Voronezh K8540 - 1000 ton (ID: 75559)
| Type | Hot forging press |
| Manufacturer | TMP Voronezh |
| Model | K8540 |
| Maximum force ton-force | 1000 ton |
| Slider stroke length | 250 mm |
| Distance adjustment between table and slider | 20 mm |
| Number of courses Sliderа | 90 |
| The open height | 560 mm |
| Table overall dimensions | 770 х 990 mm |
| Slider overall dimensions | 720 х 720 mm |
| Maximum force | 5 ton |
| Main electric motor power | 55 kW |
| Press overall dimensions | |
| Length | 4350 mm |
| Width | 3500 mm |
| Height above floor level | 5145 mm |
| Press weight | 65150 kg |
