Abgratpresse Smeral LDO 500 A - 500 ton
Technische Daten (EN) - Abgratpresse Smeral LDO 500 A - 500 ton (ID: S88893)
| Type | Trimming press |
| Manufacturer | Smeral |
| Model | LDO 500 A |
| Year of manufacture | 1987 |
| Nominal forming force | 500 ton |
| Slide stroke | 250 mm |
| Slide adjustment | 160 mm |
| Shut height | 680 mm |
| SPM | 38 |
| Number of utilizable strokes per min | 20 |
| Bed size | 1580 x 1100 mm |
| Ram size | 1570 x 1100 mm |
| Electric motor output | 47 kW |
| Dimensions L x W x H | 5400 x 2800 x 2600 mm |
| Total weight | 43 ton |
