Umformpresse Erfurt PKZV I 1250 FS - 1250 ton
Technische Daten (EN) - Umformpresse Erfurt PKZV I 1250 FS - 1250 ton (ID: 75940)
| Type | Stamping press |
| Manufacturer | Erfurt |
| Model | PKZV I 1250 FS |
| Year of manufacture | 1978 |
| Max. ram force | 1250 ton |
| Slide stroke | 630 mm |
| Slide adjustment | 630 mm |
| Stroke down, adjustment up | 1250 mm |
| Number of connecting points of the ram | 4 |
| Table | 4000 x 2500 mm |
| Moveable table | Yes |
| Slide area | 3950 x 2500 mm |
| Opening in the bed | 3320 x 1540 mm |
| Distance between columns (L-R) | 4050 mm |
| Cushion capacity | 250 tons |
| Cushion stroke | 250 mm |
| Ejection force | 40 tons |
| Strokes per minute | 11 |
| Overload protection | Yes |
| Main drive | 132 kW |
| Height above floor | 9700 mm |
