Mechanische Presse KE2330 - 100 ton
Technische Daten (EN) - Mechanische Presse KE2330 - 100 ton (ID: 75211)
| Type | Mechanical press |
| Manufacturer | |
| Model | KE2330 |
| Maximum force | 100 ton |
| Slider stroke length, adjustable | 10-130 mm |
| Slider strokes per minute | 100 |
| Maximum distance between table and slider | 400 mm |
| Size of adjustment of distance between down-stamp a plate and slider | 100 mm |
| Table overall dimensions | |
| From front to rear | 630 mm |
| From left to right | 950 mm |
| Press overall dimensions | |
| Length | 1745 mm |
| Width | 2360 mm |
| Weight | 3180 mm |
| Press weight | 7840 kg |
